■ The entire machine of this model is made of precision steel, with a compact structure that is safe, sturdy, and durable;
■ The special claw knife rotor design makes it easier and more convenient for the machine to crush materials;
■ The cutting tool is made of SKD-11 material, and the dynamic cutting tool is designed with telescopic adjustment. The blade can be sharpened with a blunt edge, making it durable and long-lasting;
■ The body is equipped with a cooling water circulation system to eliminate the heat generated by the machine during operation, effectively avoiding the phenomenon of clumping of crushed materials.
| Model | XMK-15C | XMK-20C | XMK-30C | |
| Fixed blade knife | 2*2 | 2*2 | 2*2 | |
| Rotating knife | 3*7 | 3*8 | 3*11 | |
| Grinding chamber diameter | mm | 420*270*Φ300 | 480*340*Φ350 | 660*400*Φ380 |
| Power | kw | 11KW/15HP | 15KW/20HP | 22KW/30HP |
| Rotating speed | 540 | 540 | 540 | |
| Crushing ability | mm | 300-500 | 350-550 | 500-800 |
| Sieve aperture | mm | Φ8 | Φ10 | Φ10 |
| Weight | kg | 800 | 1200 | 1500 |
| Dimensions | L*W*H mm | 1320*900*1540 | 1560*960*1850 | 1700*1200*1900 |
We reserve right to change specifications without prior notice.
